Applications
Single probe air gap tolerant double sheet detector of ferrous materials
No force after measurement
Exchangeable sensors for sheet thickness from 0.1 to 12 mm.
Optional: Version 4P allows the connection of up to four double blank sensors
Technical data
|
Applications: |
Double sheet detection in vacuum destacker, robot loader,
press feeder |
|
Material thickness: |
Steel: 0.1 - 12 mm (.004 - .472 in) |
|
Measuring method: |
single probe double sheet detection |
|
Functional principle: |
Electromagnetic double sheet sensor |
|
Programs: |
255 measurement programs possible |
|
Special features: |
Linearized air gap tolerant double sheet sensors
Up to four double sheet sensors of the same type can be connected (Version 4P)
Short measurement cycles
|
